Tape 30 degrees Hexagon needle spring loaded test probe Guide Pins

Tape 30 degrees Hexagon needle spring loaded test probe Guide Pins

  • Brand:SFENG
  • Item number:SF4015
  • Size: dia10*L30mm
  • Plunger:Brass,Ni plated
  • Barrel:Brass,Ni plated
  • Spring:SUS304
  • Packing:Plastic bag and loaded into carton box
  • Product Details

Production specifications

 Item number  SF4015
 Size
 dia10*40.0mm
 Material
 Plunger:Brass, Ni plated
 Barrel:Brass, Ni plated
 Spring:SUS304
 Rated Stroke  5.0mm
 Spring force  200gf@load 5.0mm
 MOQ  100PCS
 Payment  T/T
 Delivery time  5-15days after receiving the payment

Product Pictures







Production Flow



Testing Equippment



Packing



Main products

1.Spring loaded pin(single)for PCB,ICT,FCTtesting etc;
2.Pogo pin(connector)to establish connection between two printed circuit boards for charging,locating,battery,semiconductor&interconnector applications;
3.Double ended probes for BGA and semiconductor testing;
4.Universal pin without spring,coating pin,LM pin with QZ and VZ series;
5.High current probe,switch probe,capacitance needdle;
6.Terminal&receptacle/socket;
7.Other related electronic components,Jig locks,POM and etc.
Whatever you want,please contact us without hesitation ,and we will try our best to meet your requirement within our capability.

Our service

1.We can reply your inquiry within 24 working hours;
2.Customized design is availble and OEM are welcomed;
3.We can deliver the probe pins to our clients all over the world with speed and precision.
4.We can provide the lowest price with high quality products to our clients.

Suzhou Shengyifurui Electronic Technology Co., Ltd

Tel:+8618550184909

Wechat:+8618550184909

Contact Person:Emily

PDF Show:PDF
