Materials and finishes: Plunger: SK4, Ni or Gold plated
                        Barrel: Phosphor bronze, Gold plated
                        Spring: Music Wire
Current ration: 0.3A
Contact resistance: 50mΩ

Package: 100pcs/polybag
MOQ: 100pcs
Production lead time:10-15days

Materials and finishes: Plunger: SK4, Ni or Gold plated
                        Barrel: Phosphor bronze, Gold plated
                        Spring: Music Wire
Current ration: 0.3A
Contact resistance: 50mΩ

Package: 100pcs/polybag
MOQ: 100pcs
Product Lead time: 10-15days

Material: Plunger: SK4, Ni or Gold plated
          Barrel: Bronze, Gold plated
          Spring: Music wire; Gold plated
Size: L.11.5mm
Current ration: 0.3A
Contact resistance: 50mΩ

Package: 100pcs/polybag
MOQ:100pcs

Usage: PCB/Battery test

Item Code:SF-switch-2.38*57.80-J
Material: Barrel: Brass, Ni plated
          Plunger: 1214 Fe, Ni plated
          Spring: SUS
Full stroke:6.9mm
Rated stroke:4.6m
Spring force: 250g±20%
Switching path:2.8mm

Model: SF-1.67x44-G
Material: Barrel: Brass, Gold Plated
          Plunger: Brass, Gold Plated
          Spring: Spring Wire
Current ration: 3A
Contact resistance：50mΩ
Spring force：100g±20g

Model: SF-PPA ø2.0x4.8
Material: Becu, Brass or Bronze or SUS
Spring force:150g
Delivery Time: 5-10 working days
Payment term: 100% T/T before shipment
Place of origin: Zhejiang, China

Item: SF-PV1-H-H M7×24.5
Materials:Brass or BeCu or Bronze
Surface:Glad plated
Current ration: 30A
Packaging: plastic box, into cartons;

Item:Pogo Pin SF-PPA9.0*29-G
Material:Brass
Size:diameter 9.0mm * length 29mm
Current ration:10A,
Packing: Plastic box and loaded into carton

probe test pin
size:we have some standard pogo pin,we we can also customized pogo pins
plunger material:brass gold plated
barrel material:brass gold plated
spring:music wire
sample:we can provide samples

Material and finishes
Plunger:BeCu,gold plated over nickel,
Barrel:Brass,Gold plated over nickel,
Spring:Music wire;
Current ration:5A;

Item: 30 A Coaxial probe PV1-H-H M7-24.5
Materials:
Barrel: Brass, Au or Ni plated
Plunger: Brass, Au or Ni plated
Spring: SUS 304

Materials and finishes:Plunger: Be Cu, Rh plated
                       Barrel: Brass, Gold plated
                       Spring: Stainless steel
Spring force: 250g
Weight: 0.02kg
Current ration: 5A
Contact resistance: 50mΩ
Application: ICT/FCT Test
