Cable Harness Test probe SF-113-305-300-A-2002M,
size: diameter 2.65mm by length 28.3mm,
plunger material:brass,gold plated,
barrel material:brass,gold plated,
spring:music wire,
current ration: 10A,
contact resistance:≤50m Ω，
full stroke: 5.3mm,
rated stroke: 3.5mm,
spring force: 200g±25gf @ load 3.5mm rated stroke,
leat time: about 2 working days if we have stock or about 12 days if we have no stock,

Item: FCT test probe SF-PH101-B
Material: stainless steel and plastic pom;
Size:ø2.0*52.0mm
Packaging: plastic box into cartons;

Item:Pogo Pin SF-PPA9.0*29-G
Material:Brass
Size:diameter 9.0mm * length 29mm
Current ration:10A,
Packing: Plastic box and loaded into carton

Item Name:ICT test probe SF-PS160-T1.36*10.56MM
Material: Brass
Finish: Ni-plated or Gold-plated
Packing: Plastic box and loaded into carton

Item: ICT test probe SF-PH15-B3
Material: stainless steel and plastic pom;
Size:ø3.5*54.0mm
Packaging: plastic box into cartons;

Item: Customized SMT Pogo Pin
Material: Brass or Bronze or Becu;
Spring force: 150g or customized;
Current ration: 3A or customized;
Size: Customized;
Packaging: plastic box, into cartons;

Item name:Surgical Pogo Pin SF-PA5.8 by 36-J/M3
Material and finishes
Plunger:Brass,gold plated over nickel plated;
Barrel:Brass,Gold plated over Nickel plated;
Spring:Stainless steel;
Spring force: 400g;
Current ration: 3A;
durability: 10000cycles at least;
Contact resistance: 50m ohm;
Full stroke: 10mm;
