SFENG Switching Probes Cable Harness Testing

SFENG Switching Probes Cable Harness Testing

  • Material: brass
  • Plating: Au on Ni plated
  • Current: 3A
  • Full stroke: 5.2mm
  • Switching Path: 1.7mm
  • Spring force: 70gf @ load 1.7mm
  • Lifetime: 300,000 times
  • Application:wiring harness, testing jigs, fixtures to various automotive industries.
  • Product Details
About Us

SFENG was founded in 1984 and headquartered in Ningbo. It is a professional enterprise integrating research, development, production, and sales. (Board Test Switch Probes - Smiths Interconnect) Products include in-circuit spring test probe, semiconductor spring test probe, battery charging pogo pin and the related accessories. Products are widely used in technology, automobiles, energy, telecommunications, medical, and other peripheral electronic products.



Product Specification:

A Switch Probe is a spring contact probe and receptacle combination that is normally open, and after a designated travel the switch probe closes.

The most common use for switch probes is in the cable harness testing industry.






Product Parameters:



Product Name

Switch test probes

Item No.

SF265-F300-425L-102L-400G

Material

Brass

Plating

Au on Ni plated

Current

3A

Spring force

70gf @ load 1.7mm

Leadtime

7-10 days





Our Service

1. We can reply your inquiry within 24 working hours.
2. Customized design is available and OEM are welcomed.
3. We can deliver the probe pins to our clients all over the world with speed and precision.
4. We can provide the lowest price with high quality product to our client




Main Products

1.Spring loaded pin (single) for PCB, ICT, FCT testing etc;
2.Pogo pin (connector) to establish connection between two printed circuit boards for charging, locating, Battery, Semiconductor &  Interconnect applications;
3.Double ended probe for BGA and Semiconductor testing;
4.Universal pin without spring, coating pin, LM pin with QZ and VZ series;
5.High current probe, Switch probe, Capacitance needle;
6.Terminal & receptacle /socket;
7.Other related electronic components, 30# OK wire, Jig locks, POM, Iron hinge etc

If you require custom items,please feel free to send us inquiry for more solutions!



Package:









Production Flow




Quality Control








FAQ:

Q1.Are you a manufacturer?

A1:  Yes, we are an experienced manufacturer with our own molds and production lines.



Q2.How about quality of products?

A2: Our technicians and QC teams test the products one by one using aging line,  professional devices and instruments to ensure the quality for all products.



Q3.How about price?

A3: We are a manufacturer and always offer our customers the most competitive prices.



Q4.How to place an order?

A4: Contact with online service, or sent email to us directly, we will reply to you with product price, specifications, packing etc. soon. Thank you.



Q5.May I buy samples from you?

A5: Yes! You are welcome to place sample order to test our superior quality and service, mixed samples are acceptable.



Q6.Can I visit your factory?

A6: Yes, welcome to visit our factory at your convenient time.



Q7.How can I make OEM or ODM orders?

A7: We have different print processing for different OEM/ODM orders. Please contact us with online service or send email to us directly.



Q8. How should I pay for my orders?

 A8: You can pay by T/T, L/C at sight would be available for qualified bank and MOQ required for each order.



Logistics:



Sample order ship by DHL, UPS, FedEx, TNT, EMS etc

For mass order delivery, can be optional with terms of Exwork, FOB, CNF, CIF by air or by sea based on the buyer’s forwarder or ours




Certifications

Factory Show:








Exhibition & Fair




Suzhou Shengyifurui Electronic Technology Co., Ltd

Tel:008613862105944

Contact Person:Eve

PDF Show:PDF

Send Us An Inquiry
We will contact you as soon as possible!
Phone
Phone
WeChat
Skype
Whatsapp
captcha
If you have questions or suggestions,please leave us a message,we will reply you as soon as we can!

RELATED PRODUCTS

Highly customized tea processing machine to meet your special needs, strictly product quality control is our requirement .

ICT test switch probe

ICT test switch probe
Model Number:switch probe SF-3.15x49-A
Model Number:switch probe SF-2.96*49MM
Plunger material:Be Cu, Gold plated
Barrel material:Brass, Gold plated
Insulation sleeve:peek
Solder connection:Be Cu, Gold plated
Switch probe receptacle:brass,Au plated
Spring:music sire
Current rating:3A
Switch probe condition:normally open

Switching test probe

Switching test probe
Item: switch probe SF-2.96*49MM
Material: Brass;Au plating or Nickel plating;
Packaging: plastic box into cartons;

Normally open switch test contact probe

Normally open switch test contact probe
Item: switch probe SF-2.96*49MM
Material: Brass;Au plating or Nickel plating;
Packaging: plastic box into cartons;

SFENG Switching Probe with plastic head

Brand:SFENG
Item number:SF5037
Size:dia1.67*L44mm
Packing:Plastic bag and loaded into carton box
