Type: pogo pin
Current:2A
Size:customized

Material: brass
Plating: gold plated
Current: 10A
Lifetime: 300,000 times
Application:mobile phones,portable electronic devices,communications,automobiles,etc.

Full stroke: 5.2mm
Switching Path: 1.7mm
Spring force: 70gf @ load 1.7mm
Lifetime: 300,000 times
Application:wiring harness, testing jigs, fixtures to various automotive industries.

Full stroke: 5.0mm
Switching Path: 1.5mm
Spring force: 450gf @ load 5.0mm
Lifetime: 300,000 times
Application:wiring harness, testing jigs, fixtures to various automotive industries.

Switch Probe Specifications:

Current Rating:3A

Contact Resistance:<50mΩ

Full Stroke:5.2mm

Switching Path:1.7mm

Spring Force:100~150fg@ load 5.0mm

Spring Force:200~250gf@ load 3.3mm

The total set elastic:350~400gf@ load 5.0m

Material：

Plunger: Becu

Barrel: Brass

Spring:304 Stainless Steel

Insulation Sleeve: Peek

Solder Connection:Becu

Receptacle:Brass

Plating:Au on Ni plated

Plunger: Becu

Barrel: Brass

Spring:304 Stainless Steel

Material and plating:
1.Tip:POM
2.Plunger:brass,gold plated
3.Barrel:brass,gold plated
4.Insulation sleeve:PEEK
5.End pin:Ph,gold plate

Specifications:

1.Switch distance:1.5mm

2.Spring force:100g@1.5mm

Switch Probe Specifications:

Current Rating:3A

Contact Resistance:<50mΩ

Full Stroke:7.0mm

Switching Path:2.4mm

Switch Trip Elastic:0.9N@load2.4mm

Spring Force:2.5N@load 2/3

Material：

Plunger: Becu

Barrel: Brass

Spring:Music Wire

Tip:POM

Insulation Sleeve: Peek

Solder Connection:Becu

Switch Probe Specifications:

Full Stroke:5.0mm

Current Stroke:3.5mm

Current Force:400±20%

Switching Distance:1.0±0.2mm

Material：

Plunger: Becu

Barrel: Brass

Spring:304 Stainless Steel

Materials(Plated):

1.Plunger:Becu

2.Barrel:Brass

3.Insulation Sleeve:Peek

4.Solder Connetion:Becu

5.Receptable:Brass

6.Spring:SUS304

Specifications:

Current Rating:3A

Contact Resistance:<50mΩ

Full Stroke:5.2mm

Switching Path:1.7mm

Spring Force:100~150fg@load5.0mm/200~250gf@load3.3mm

The Total Set Elastic:350~400gf@load5.0mm


Techanical Parameters:

Switch distance:1.0±0.2mm

Full stroke:5.0mm

Current Stroke:3.5mm

Current Force:400g±20%

Material:

Plunger:Becu, Gold plated

Barrel:Brass, Gold plated

Spring:304 Stainless Steel

Full stroke: 13.0mm
Rated stroke: 6.5mm
Spring force: 300±50%gf @ load 6.5mm
Lifetime: 300,000 times
Application:mobile phones,portable electronic devices,communications,automobiles,etc.
