Gold plated Spring loaded pogo pin with ball
Item: SF-PPA3.1X12-J2.4
Materials: Brass
Spring: SUS304
Finish: gold platedHot Tags : China test probe supplier China spring probe supplier PCB test probe pin spring loaded connector
Read More -
Normally open 100 mil switching probe SF-KP1.65*44.6-G1.8 (NO)
Item: Switching probe SF-KP1.65*44.6-G1.8 (NO)
Materials: Beryllium Copper
Spring: Music wire
Finish: gold platedHot Tags : China test probe supplier China spring probe supplier PCB test probe pin spring loaded connector
Read More -
Normally open 100 mil switching probe SF-KP1.65*44.6-J1.0 (round tip)
Item: Switching probe SF-KP1.65*44.6-J (round tip)
Materials: Beryllium Copper
Spring: Music wire
Finish: gold platedHot Tags : China test probe supplier China spring probe supplier PCB test probe pin spring loaded connector
Read More -
Normally open 100 mil switching probe SF-KP1.65*44.6-A1.5
Item: Switching probe SF-KP1.65*44.6-A1.5
Materials: Beryllium Copper
Spring: Music wire
Finish: gold platedHot Tags : China test probe supplier China spring probe supplier PCB test probe pin spring loaded connector
Read More -
100mil ø1.8 Cup tip screw probe for cable harness testing
Item: SF-L106-A1.8
Material:Brass
Finish:Gold platedHot Tags : China spring pogo pin supplier China test probe supplier China spring probe supplier semiconductor testing spring loaded connector
Read More -
SFENG Brand Screw-in Test Probe with Competitive Price
Poduct Name SFENG Brand Screw-in Test Probe with Competitive Price Item No. SF-T-899-305-065-M Material Plunger:Becu
Barrel:Brass
Spring:Stainless Steel
Surface Plating Au plated over nickel Current Rating 3A Contact Resistance(lnitial) ≤50mΩ Full Stroke 4.4mm Rated Stroke 3.5mm Spring Force 200±20%gf Load4.4mm Hot Tags : China spring pogo pin supplier China test probe supplier China spring probe supplier spring loaded connector screw in test probe pin
Read More -
Professional Manufacturer 38mm Length Threaded Probe
Product Name Professional Manufacturer 38mm Length Threaded Probe Item No. SF-L112-FT1.0-3.0-R2 Material Plunger:Becu
Barrel:Brass
Spring:SWP
Plating Au plating on Nickel Current Rating 3A Samples Samples can be provided Lead Time 7-10days Hot Tags : China spring pogo pin supplier China test probe supplier China spring probe supplier spring loaded probe pin spring loaded connector screw in test probe pin
Read More -
Free Sample Wiring Harness Screw-in Type Test Probe Pins
Parameters：
Current Rating:5A
Contact Resistance:≤50mΩ
Full Stroke:5.30mm
Rated Stroke:4.0mm
Spring Force:150±25gf@load4.0mm
Materials:
Barrel:Brass
Plunger:Becu
Spring:SWP
Plating:Au on Ni plated
Hot Tags : China spring pogo pin supplier China test probe supplier China spring probe supplier spring loaded probe pin spring loaded connector screw in test probe pin
Read More -
High Quality Customized Screw-in Probes for Automotive Sector
1.Parameters：
Current Rating:5A
Contact Resistance:≤50mΩ
Full Stroke:5.30mm
Rated Stroke:4.0mm
Spring Force:150±25gf@load4.0mm
2.Materials:
Barrel:Brass
Plunger:Becu
Spring:SWP
Plating:Au on Ni plated
Hot Tags : China spring pogo pin supplier China test probe supplier spring loaded connector screw in test probe pin spring loaded probe pin
Read More -
High Performance SF-L106 Series Screw-in Probe
Material:
Barrel:Brass
Plunger:Becu
Spring:SWP
Plating:Au on Ni plated
Hot Tags : China spring pogo pin supplier China test probe supplier China spring probe supplier spring loaded probe pin spring loaded connector screw in test probe pin
Read More -
Factory Direct Sale 3A ICT Switch Probe
Switch Probe Specifications:
Current Rating:3A
Contact Resistance:<50mΩ
Full Stroke:5.2mm
Switching Path:1.7mm
Spring Force:100~150fg@ load 5.0mm
Spring Force:200~250gf@ load 3.3mm
The total set elastic:350~400gf@ load 5.0m
Material：
Plunger: Becu
Barrel: Brass
Spring:304 Stainless Steel
Insulation Sleeve: Peek
Solder Connection:Becu
Receptacle:Brass
Plating:Au on Ni plated
Hot Tags : China spring pogo pin supplier China test probe supplier China spring probe supplier spring loaded probe pin spring loaded connector Switching pogo pin Switch test connector
Read More -
Competitive Price Brass Material Switch Contact Pin
Plunger: Becu
Barrel: Brass
Spring:304 Stainless Steel
Hot Tags : China spring pogo pin supplier China test probe supplier spring loaded connector Switching pogo pin Switch test connector
Read More
