Brand: SFENG
Model: SF33-4-19-6A
Material: Copper Alloy
Finishes: Partial gold-plated over nickle
Plastic Base: Nylon+Glass Fiber

MOQ:100pcs
payment term: 100% TT in advance

Brand: SFENG
Model: SF-9.0*62.0
Material: Copper Alloy
Finishes: Plated gold over Nickle
Current rating: 60A
Full Compression Travel: 10.0mm
Spring force: 4200g±20%
MOQ: 100pcs

Brand: SFENG
Item number:SF-20.0*76.5
Material:
Barrel: Brass, Au on Ni plated
Plunger: Becu, Au on Ni plated
When Voltage pin pressed to 3.0mm, the spring force can up to 600g±20%
When current pin pressed to 5.0mm, the spring force can up to 10kg ±20%，the Maximum full stroke ≥10mm；
When  300A current， contact resistance≤1mOhm
Packing:Plastic bag and loaded into carton box

Brand: SFENG
Item number:SF-20.0*76.5
Material:
Barrel: Brass, Au on Ni plated
Plunger: Becu, Au on Ni plated
When Voltage pin pressed to 3.0mm, the spring force can up to 600g±20%
When current pin pressed to 5.0mm, the spring force can up to 10kg ±20%，the Maximum full stroke ≥10mm；
When  300A current， contact resistance≤1mOhm
Packing:Plastic bag and loaded into carton box

Brand: SFENG
Model: PV1-H-H M11*26.5
Material:
Plunger 1 (dia.1.5): Becu, Gold plating
Plunger 2 (dia.10): Brass, Gold plating
Barrel: Brass, Ni plated
Spring: SUS304
MOQ: 100pcs

Brand:SFENG
Item number:SF-PPA8.0*22-G
Material:
Barrel:Brass, Au on Ni plated
Plunger:Becu, Au on Ni plated
Spring: SWP
Size:dia8.0*22mm
Packing:Plastic bag and loaded into carton box

Item Code: SF-PPA2.0X10.1-D
Material: Brass, SUS304
Plating: Ni plating
Spring force: 85g
Full Stroke:5.5mm
Rated Stroke:3.3mm
Packing: Plastic box and loaded into carton

Item Code: SF-PV1-H-H M8*26.5
Material: Brass, Becu, SUS304
Plating: Ni plating
Spring force: 280-300g
Packing: Plastic box and loaded into carton

Item:SF-PH420*4850-H
Material:
Barrel: Brass, Au on Ni plated
Head: Becu, Au on Ni plated
Plunger: Ph, Au on Ni plated
Spring: SUS
Size:dia.4.2*48.5mm
Packing: Plastic box and loaded into carton

Item: SF-32*83.5
Materials:Brass, Becu, PEEK, SUS304
Surface:Au plated
Size:dia.12*83.50mm
Current 2A
Packaging: plastic box, into cartons

Item: SF-420 * 4820
Materials: Brass
Surface: Glad Plated
Size: 4.2 * 48.20mm
Packaging: plastic box, in cartons

Item:SF-2.9*36
Material: Plunger: Becu; AU Planting
          Barrel: Brass; AU Planting
          Spring: SWP
          Barrel: PEEK
Size:ø2.9*36mm
Current ration: 6A;
Resistance: ＜10mΩ
Temperature：△T＜20℃
Packaging: plastic box into cartons;
