Product Specification
|
Brand |
SFENG |
|
Item number |
SF-P156 |
|
Plunger |
Brass or Becu,gold or Ni plated |
|
Barrel |
Brass,gold or Ni plated |
|
Spring |
SK4,music wire |
|
Spring Force |
250g |
|
Full Travel |
6.3mm |
|
Current Ration |
5A |
|
Current Resistance |
50mΩ |
|
Pitch |
4.75mm |
|
Mounting hole size |
2.75mm |
|
MOQ |
100 pcs |
|
Lead time |
7 working days after receiving the payment |
Product Picture
Our Service
1.Reply your inquiry withn 24 working hours
2.Customized design is available,OEM are welcomed
3.Delivery the probe pins to our clients all over the world with speed and precision
4.provide the lowest price with high quality to our client
Main Products
---Spring loaded pin(single) for PCB,ICT,FCT testing,etc;
---Pogo pin(connector) to establish a(usuallytemporary)connection between
two printed circuit boards for charing, locating, Battery, Semiconductor &
interconnectApplications;
---Double ended probef orBGA&semiconudtion testing;
---Universal pin without spring,coatingpin,LM pin withQZ&VZseries;
---High current probe,Switch probe,Capacitance needle...
---Terminal&receptacle/socket;
---Other related electronic compents,30#OKwire,Jig locks,POM,Ironhinge,etc
Quality Control
Packing Picture
Highly customized tea processing machine to meet your special needs, strictly product quality control is our requirement .
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.90mm
Spring Force:39g±20% at 0.65mm
Electrical:
Current Rating:3.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>25GHz@-3dB
Model Number:
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.50mm
Spring Force:28g±20% at 0.35mm
Electrical:
Current Rating:1.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>29GHz@-3dB
MOQ:100pcs
Leadtime:7-10days
Model Number:SF-057F310F25
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.70mm
Spring Force:25g±20% at 0.50mm
Electrical:
Current Rating:3.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>25GHz@-3dB
MOQ:100pcs
Leadtime:7-10days
Model Number:SF-051B570F23
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:1.00 mm
Spring Force:23g±20% at 0.65mm
Electrical:
Current Rating:3.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>19GHz@-3dB
MOQ:100pcs
Leadtime:7-10days
Model Number:SF-038B570U35
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.80mm
Spring Force:35g±20% at 0.65mm
Electrical:
Current Rating:2.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>16GHz@-3dB
Model Number:SF-031B300U22
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.75mm
Spring Force:22g±20% at 0.50mm
Electrical:
Current Rating:1.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>29GHz@-3dB
Model Number:SF-031B255U18
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.60mm
Spring Force:18g±20% at 0.45mm
Electrical:
Current Rating:1.0A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>27GHz@-3dB
Model Number:SF-020B240J13
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.50mm
Spring Force:13g±20% at 0.45mm
Electrical:
Current Rating:0.5A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>25GHz@-3dB
Model Number:SF-020J220U
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.50mm
Spring Force:13g±20% at 0.45mm
Electrical:
Current Rating:0.5A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>25GHz@-3dB
Material:
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Mechanical:
Full Travel:0.65mm
Spring Force:14g±20%at 0.50mm
Electrical:
Current Rating:0.5A
Contact Resistance:<50mΩ(AVG)
Bandwidth:>19GHz@-3dB
MOQ:100pcs
Leadtime:7-10days
Plunger:BeCu /Au Plated
Plunger:BeCu /Au Plated
Barrel:PhBz /Au Plated
Spring:SWP /Au Plated
Full Travel:0.80mm
Spring Force :21g±20%at 0.50 mm
Current Rating:0.5A
Contact Resistance:<50mΩ(AVG)
Bandwidth :>15GHz@-3dB
MOQ:100pcs
Leadtime:7-10days
Material:
Plunger : Becu / Au on Ni Plated
Plunger : SK4 / Au on Ni Plated
Barrel : PhBz / Au on Ni Plated
Spring : SWP
Mechanical:
Full Travel : 6.8 mm
Electrical:
Contact Resistance : 100mohm
Material:
Plunger : Becu / Gold Plated
Plunger : Becu / Gold Plated
Barrel : PhBz / Gold Plated
Spring : Music wire / Gold Plated
Mechanical:
Full Travel : 1.10 mm
Electrical:
Contact Resistance : 100mohm
Cycle time: 100,000times
Item: Double head pin SF-0.86*18.5-BB
Material:
-Barrel: Ph, Au on Ni plated
-Plunger: Becu, Au on Ni plated
-Spring: SWP
Packaging: plastic box into cartons
Payment term: 100%TT in advance
Item: Double Head Pin SF-1.36*21.2-JJ
Material:
Barrel: Brass, Au on Ni plated
Plunger: Becu, Au on Ni plated
Spring: SUS
Size: ø1.36*21.2mm
Current Rating: 3A
Contact Resistance: 80mΩ
Full Stroke: 6.50mm
Rated Stroke: 4.30mm
Spring force: 70±10gf@ load 4.30mm
Packing: Plastic box and loaded into carton
Payment term: 100% TT in advance
Item: SF-1.36*20.8-JJ
Material:
-Barrel: Brass, Au on Ni plated
-Plunger: Becu, Au on Ni plated
-Spring: SUS
Packaging: plastic box into cartons
Payment term: 100%TT in advance
Item:SF-PP2.65*14.9
Material:
Barrel: Phosphor Bronze, Au on Ni plated
Plunger: Brass, Au on Ni plated
Spring: SUS304
Current Rating: 5A
Contact Resistance:40mΩ
Full Stroke: 1.7mm
Spring Force: 300g
Packing: Plastic box and loaded into carton
Item:SF-GB031D570D20-BB-A6
Material: Music Wire, Phosphor Copper, Becu
Finish: Gold-plated
Size: dia.0.31*5.7
Spring force:20g
Packing: Plastic box and loaded into carton
Brand:SFENG
Item number:SF6592
Size: dia0.31*L3.30mm
Plunger:Becu
Barrel:Phosphor Copper
Spring:SWP
Finish:Gold plated
Packing:Plastic bag and loaded into carton box
